millimeter wave filter customized

model

bandpass(GHz)

IL(dB)

VSWR

60dB rejection f1 (GHz)

60dB rejection f2 (GHz)

connector

size(mm)

FL2WG29CI16EV11-0214

26.5-31

1.5

1.5

25.28

34.4

BJ320

60*24*20

FL3PN33CI40CL11-0272

26.5-40

1.1

2

24.5

0.38mm Pin

50*14*12

FL2CX30CX18CL11-0259

27.5～33

1

2

24.79

37.28

2.92-K

57*14*11

FL2CX29CX12CL11-0284

27.5-31

1.5

2

26.8

31.9

0.38mm Pin

78*16*12

FL2CX30CI10CL10-0209

28.5-31.5

1.5

2

20*5.4*4.5

FL2CX30CX08CL11-0235

28.5-31.8

0.8

1.5

25.275 (40dB)

36.975 (45dB)

0.38mm Pin

20*6*6

FL2CX31CX18CL11-0267

28-33.5

1.2

2

25.37

36.63

2.92-K

58*15*11

FL2WG30WG16NM09-0125

29.14-30.4

1.3

1.6

28.51

31.36

BJ320

53*20*20

UF2CX03CI10CL10-0187

3.1-10.6

1.1

2

1 (48dB)

1.143 (35dB)

SMA-K

115*36*28

FL2WG32CI13EV11-0215

30-34

2

1.5

29

37.4

BJ320

61*24*20

FL2CX32CI03CL10-0169

31-32

2

2

28.5 (47dB)

34.84 (50dB)

0.38mm Pin

40*13*6

FL2CX32CI03CL10-0180

31-32

2.4

2

30.2

33

2.92-K

67*13*11

FL2CX35CI06CL11-0230

33.6-36.4

1.3

1.5

31.7 (50dB)

39 (33dB)

2.92-K

52*13*10

FL2WG35CI11EV11-0216

33-37

1

1.5

BJ320

64*24*20

FL2WG34CI02CL11-0226

34.5

0.7

1.5

BJ320

27*20*20

FL2WG36WG01EV07-0029

35.13-35.83

2

2

32.39 (50dB)

35.87 (50dB)

BJ320

34*19*19

FL2WG38CI11NM11-0217

36-40

1

1.3

34.1

BJ320

49*24*20

FL2WG38WG02DM09-0108

37.67-38.33

1.5

2

37.41

38.61

BJ320

47*21*20

FL2CX40CX3CL11-0274

39.44-40

0.6

1.2

36.63

2.92-K

47*14*11

FL2WG40WG00NM10-0203

39.8-39.82

3

1.5

39.3 (50dB)

40 (25dB)

2.92-K

53*13*9
