millimeter wave filter 5004

millimeter wave filter 5004

    • millimeter wave filter 5004
    • millimeter wave filter 5004
    • millimeter wave filter 5004

    Product Details:

    Place of Origin: wuxi
    Brand Name: HM
    Certification: Pass-band low-loss, high rejection stopband, rectangular coefficient good
    Model Number: GHZ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1500
    Price: 2000.0 RMB
    Packaging Details: REEL
    Delivery Time: 25 day
    Payment Terms: 现金
    Supply Ability: 1000000
    Contact Now
    Detailed Product Description

    millimeter wave filter 5004millimeter wave filter 5004
    L*W*H
    mm
    28.7*8.4*13.24




    model

    passband(GHz)

    Max.IL(dB)

    Stopband1 (GHz)

    Stopband2 (GHz)

    FL2CX29CX05-5004A

    28.275-29.725

    2.4

    27.3,50dB

    30.8, 50dB

    FL2CX28CX05-5004B

    27.3-28.7

    2.5

    26.3,50dB

    29.7,50dB

    FL2CX27CX05-5004C

    26.325-27.675　

    2.7

    25.4,50dB

    28.7,50dB

    FL2CX29CX07-5004D

    27.985-30.015　

    3　

    26.6,50dB　

    31.6, 50dB　

    FL2CX28CX07-5004E

    27.02-28.98　

    3.2　

    25.7,50dB

    30.5, 50dB　

    FL2CX27CX07-5004F

    26.055-27.945　

    3.5　

    24.7,50dB　

    29.4,50dB　
