millimeter wave filter 5003

millimeter wave filter 5003

    • millimeter wave filter 5003
    • millimeter wave filter 5003
    • millimeter wave filter 5003

    Product Details:

    Place of Origin: wuxi
    Brand Name: HM
    Certification: Pass-band low-loss, high rejection stopband, rectangular coefficient good
    Model Number: GHZ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1500
    Price: 2000.0 RMB
    Packaging Details: REEL
    Delivery Time: 25 day
    Payment Terms: 现金
    Supply Ability: 1000000
    Contact Now
    Detailed Product Description

    millimeter wave filter 5003millimeter wave filter 5003
    L*W*H
    mm
    30.1*8.5*13.6




    model

    passband(GHz)

    Max.IL(dB)

    Stopband1 (GHz)

    Stopband2 (GHz)

    FL2CX26CX05-5003A

    25.35-26.65

    2.2

    24.4,50dB

    27.6, 50dB

    FL2CX25CX05-5003B

    24.375-25.625

    2.4

    23.5,50dB

    26.6,50dB

    FL2CX24CX05-5003C

    23.4-24.6

    2.5

    22.6,50dB

    25.5,50dB

    FL2CX26CX07-5003D

    25.09-26.91　

    2.8　

    23.8,50dB　

    28.3, 50dB　

    FL2CX25CX07-5003E

    24.125-25.875

    3　

    22.9,50dB

    27.2, 50dB　

    FL2CX24CX07-5003F

    23.16-24.84　

    3.3　

    22,50dB　

    26.1,50dB　
