Sales & Support: Request A Quote
Home Productsfilter

millimeter wave filter 5001

millimeter wave filter 5001

    • millimeter wave filter 5001
    • millimeter wave filter 5001
    • millimeter wave filter 5001

    Product Details:

    Place of Origin: wuxi
    Brand Name: HM
    Certification: Pass-band low-loss, high rejection stopband, rectangular coefficient good
    Model Number: GHZ

    Payment & Shipping Terms:

    Minimum Order Quantity: 1500
    Price: 2000.0 RMB
    Packaging Details: REEL
    Delivery Time: 25 day
    Payment Terms: 现金
    Supply Ability: 1000000
    Contact Now
    Detailed Product Description

    model

    passband(GHz)

    Max.IL(dB)

    Stopband1 (GHz)

    Stopband2 (GHz)

    FL2CX20CX05-5001A

    19.5-20.5

    2.0

    18.8,50dB

    21.2,50dB

    FL2CX19CX05-5001B

    18.5-19.5

    2.1　

    17.8,50dB　

    20.2,50dB　

    FL2CX18CX05-5001C

    17.55-18.45　

    2.2

    16.9,50dB

    　19.1,50dB

    FL2CX20CX07-5001D

    19.36-20.66　

    2.5　

    18.4,50dB　

    21.6,50dB　

    FL2CX19CX07-5001E

    18.36-19.66　

    2.7　

    17.5,50dB

    20.6,50dB　

    FL2CX18CX07-5001F

    17.36-18.66　

    3.0　

    16.5,50dB　

    19.6,50dB　

    L*W*H
    mm
    33.01*8.75*13.71
    millimeter wave filter 5001millimeter wave filter 5001

    Contact Details
    hanse-john electronic Co.,Ltd.

    Contact Person: Mr. liuhongmao

    Tel: 86-0510-13912395130

    Fax: 86-510-88213035

    Send your inquiry directly to us (0 / 3000)
